Aqara Smart Door Lock N100 Zigbee
Versatile smart door lock with multiple unlocking methods and compact design
Versatile Smart Door Lock with Comprehensive Access Control
The Aqara Smart Door Lock N100 Zigbee is a versatile and compact smart door lock that offers multiple unlocking methods including fingerprint recognition, NFC, and PIN codes. Designed for easy installation and everyday use, it provides reliable security and convenient access control while seamlessly integrating with the Aqara smart home ecosystem.
How It Works
The N100 features a precise fingerprint sensor for quick biometric access, along with NFC card support and a backlit numeric keypad for PIN code entry. The lock automatically engages when the door closes and can be controlled remotely through the Aqara app when connected to an Aqara hub. It supports temporary access codes for guests and integrates with other Aqara devices to create automated home security scenarios and smart home routines.
Technical Specifications
| Specification | Details |
|---|---|
| Model | N100 Zigbee |
| Unlock Methods | Fingerprint, PIN code, NFC cards, App control, Mechanical key, Temporary password |
| Wireless Protocol | Zigbee 3.0 |
| Fingerprint Capacity | Up to 50 fingerprints |
| User Capacity | Up to 50 users |
| PIN Code Features | Backlit keypad, temporary codes, one-time codes |
| Auto-lock Feature | Auto-lock after door closes |
| Power Supply | 4×AA batteries |
| Battery Life | Up to 12 months (normal use) |
| Backup Power | USB-C emergency power |
| Lock Mechanism | Motorized deadbolt |
| Security Features | Anti-tamper alarm, wrong attempt lockout, door status monitoring |
| Operating Temperature | -20°C to 55°C |
| Door Thickness | 35-60mm |
| Finish | Black, Silver |
| Dimensions | 370 × 75 × 55 mm |
| Weight | Approx. 2.8kg |
| Installation | Standard door preparation, DIY-friendly |
